AS80 Zero air generator

Product Description

The AS80 Zero air generator is designed to provide an inexpensive source of clean, zero-grade air for flame ionisation detectors (FID). The unit removes all hydrocarbons, including methane, down to 0.1% of original  level. Up to 10 FID units can be run from one unit. The AS80 contains a high temperature furnace containing alumina pellets coated  in platinum, this oxidizes all combustible compounds to CO2 and H2O. The unit can completely remove methane at rates of up to 5 l/min high efficiency and up to 20 l/min medium efficiency.

The AS80 contains a high temperature furnace containing alumina pellets coated  in platinum, this oxidizes all combustible compounds to CO2 and H2O. The unit can completely remove methane at rates of up to 5 l/min high efficiency and up to 20 l/min medium efficiency.

Additional information

Applications

, , , , , , , , , , , , , , , , , , , , , , , , , , , , , ,

Key Features

• Replaces expensive air cylinders

• Uses replaceable, long-life catalyst

• Runs up to 5 flame ionisation detectors

• Connects direct to airline

• Incorporates a molecular sieve to prevent water vapour

• Uses high temperature furnace

• Removes all hydrocarbons, including methane

Documentation

➔ Ancillary Equipment Brochure

➔ Datasheet

➔ User Manual

Technical Specification

RANGE: Up to 500ppm methane equivalent

EFFICIENCY: Hydrocarbons reduced to below 0.1% of original level

METHOD USED: Catalytic oxidation, with molecular sieve

RATINGS: 100psig, 5l/min STP

POWER: 240V 50Hz 600W

DIMENSIONS: 19” rack mounting 3U high, 19” x 133.5mm x 570mm

WEIGHT: 15kg

COMPRESSION FITTINGS: 1/4” to 1/4” compression fitting
